Fits 0.31″ – 0.39″ PCB (8 – 10 mm PCB) – (standard 3528 / 2835 / COB tape)
0
Use BRIGHT11 code for extra 11% off
Original price was: $19.00.$9.00Current price is: $9.00.
Model number: ACL-026
This product includes the aluminum channel only. To complete your setup, LED strips, power supplies, and accessories must be purchased separately.
Original price was: $19.00.$9.00Current price is: $9.00.
Original price was: $19.00.$9.00Current price is: $9.00.
Original price was: $24.00.$14.00Current price is: $14.00.
Original price was: $39.00.$29.00Current price is: $29.00.
$9.00
Original price was: $29.99.$19.99Current price is: $19.99.
Original price was: $24.99.$14.99Current price is: $14.99.
Original price was: $19.00.$9.00Current price is: $9.00.
Original price was: $19.00.$9.00Current price is: $9.00.
Finish tiled walls, stair risers or bar fronts with a razor-clean light line and zero visible hardware. This aluminum trim channel slips under the last course of tile (or LVT, stone, wood panels), doubling as a protective edge AND a concealed LED housing. The brushed, anodized alloy blends with modern fixtures while the snap-in diffuser turns raw LED tape into a soft, uniform glow along floors, splashbacks, or ceiling coves. Sized for common 8-10 mm LED strips, it’s the architect’s shortcut to “floating” illuminated reveals without bulky coves or surface fixtures.
Need a COB strip for a pixel-free look? [CLICK HERE]
Specifications Table
| Feature | Detail |
|---|---|
| Material | 6063-T5 aluminum alloy, brushed & anodized |
| Thickness |
0.02″ – 0.12″ wall gauge (0.4 mm – 3 mm) |
| Finishes | Matte Black • Champagne Gold • Coffee Bronze • Raw Aluminum |
| Surface Treatment | Wire-drawing + clear oxidation (anti-corrosion) |
| LED Slot |
Fits 0.31″ – 0.39″ PCB (8 – 10 mm PCB) – (standard 3528 / 2835 / COB tape) |
| Diffuser | Opal silicone snap-in cover – dot-free, wipe-clean |
| Trim Function | Protects tile edge / corner; creates 10 mm reveal |
| Channel Lengths | 11.81″ (30cm) , 15.75″ (40cm) , 19.69″ (50cm) , 23.62″ (60cm) , 27.56″ (70cm) , 31.50″ (80cm) , 35.43″ (90cm) , 39.37″ (100cm) , 43.31″ (110cm) , 47.24″ (120cm) , 51.18″ (130cm) , 55.12″ (140cm) , 59.06″ (150cm) , 63″ (160cm) , 68″ (173cm) , 73″ (185cm) , 79″ (200cm) |
| Beam | 120° soft wash parallel to surface |
| Operating Temp. | -20 °C → +45 °C |
| Included | Channel, diffuser, two end caps (per bar) |
| Ideal Uses | Shower niches, kitchen splashbacks, hotel corridors, step nosing, reception desks |
Installation Notes
Plan grout line – allow a 10 mm reveal where the light will exit.
Bed the trim – set the channel in thin-set adhesive behind final tile course; ensure front lip is flush with tile face.
Pre-wire LED tape – solder leads, test, then adhere strip inside channel.
Snap on diffuser – after grout is cured, press from one end to the other for a seamless lens.
Seal ends – run a bead of neutral-cure silicone around caps for wet-area installs (IP rating depends on LED tape).
Power up – connect to 12 V / 24 V driver; dim or motion-sensor control recommended for accent and step lighting.
