COB LED Strip Light with Dupont Interface – 12V Ultra Bright 3000K Warm White Flexible Tape Lighting for Under Cabinet, Accent, and DIY Projects

Feature	Detail
Input Voltage	DC 12 V
Interface Type	DUPONT 4-pin connector (easy plug-and-play connection)
Brightness	1060 lm/m (≈ 323 lm/ft)
Efficacy	115 lm/W
Estimated Power	≈ 9.2 W/m (≈ 2.8 W/ft)
Color Quality	CRI ≥ 95 (vivid, true-to-life color)
LED Tech	COB (chip-on-board), dot-free
PCB Width / Color	8 mm / White
Cut Points	Every 50 mm (1.97 in)
Roll Length	20m (65 ft)
Adhesive	Genuine 3M peel-and-stick
Operating Temp	−20 °C to 40 °C
Waterproof	Indoor only (IP20)
CCT Options	Single-CCT variants (Warm / Neutral / Cool White – select on product page)
Applications	Under-cabinet, shelves, coves, stairs, display cases, architectural accents

Plan & measure – Lay out runs and choose CCT. Cut only at 50 mm marks.
Size the power – Budget ≈ 9.2 W per meter (≈ 0.38 A/m at 12 V). Use a regulated 12 V DC driver with 20–30% headroom.
Prep the surface – Clean and dry. For long runs or higher output, mount in an aluminum channel for heat dissipation.
Cut & connect – Maintain polarity (+/−). The DUPONT interface makes linking to controllers, dimmers, and power supplies fast and secure. Inject power on long runs to minimize voltage drop.
Mount – Peel the 3M backing and press firmly; avoid sharp kinks—use smooth bends.
Dim & control – Compatible with 12 V PWM dimmers and smart controllers (not included).
Test & seal – Power up and confirm uniform light. Keep dry (IP20).
